P/N 800105
2500mm(96 inch) Extension Lines with T Connector with Check Valve
SSIT 96 VLD MRI 2500mm (96 inch) Spiral Extension T connector Tubing with Check Valve for Single-use
Description
Application
Used with CT MRI contrast medium injectors to deliver the medicine ( Contrast Agents & NaCl Normal Saline), enhance scanning images, and facilitate doctors to observe and locate lesions more accurately.
Features
Shape: Spiral ( Straight Option)
Tube Material: PVC / PVC -Free DEHP
Connector: 6/100 Luer Lock, Including Female, Male lock connector.
ID: 1.8±0.05mm
OD: 3.25±0.05mm
Length: 2500mm/60inch
( 1500mm for CT Injection Procedure Option)
Working MAX Pressure: 24Bar/350psi
Valve: One Check Valve Option–Prevent Backflow of Contrast Agent and Saline
Shelf Life: 3 years
Certification
- CE
- ISO 13485
- FDA-US
Download
product datasheet -800104-800105 T connector with check valve
